Single Column Press - Hydraulic

neu ︱ 2024 ︱ 7305 ︱ Jänner 2024, Zwischenverk ︱ Italien ︱ 46400 €︱ 941.92 €︱ 100 to︱ 500 mm︱ 700 x 350 mm︱ 800 x 600 mm︱ 500 mm︱ 300 mm︱ 25 mm/s︱ 4 mm/s︱ 4 kW︱ 1900 mm︱ 1200 mm︱ 2600 mm︱ 2100 kg︱

---

2-fold round guidance table and ram with T-slots 2 hand operation Siemens PLC manometer users manual incl. pressure switch OPTIONS: time of delivery with options 2 - 3 months from order 4-fold round guidings € 1.900,- Light barrier € 7.300,- Siemens control for programming of stroke and press time € 4.000,- Siemens touchscreen-control, 50 programsstoreable, for programming: • Upstroke and downstroke quota • Break time in the bottom • time of Decompression • setting pressure of work • Pieces counter • prestop in upstroke and downstroke • setting for movement in manual and in automatic • management of alarms and anomalies € 9.000,- Working hour counter € 400,- Stroke counter € 400,- Deompression valve € 700,- Oil cooler with decompreission valve € 3.700,- Pressure switch € incl.

Press capacity 30 t︱Stroke 400 mm︱Daylight 500 mm︱Table surface area 500 x 500 mm︱Approach speed 100 mm / s︱Working speed 10 mm / s︱Return speed 150 mm / s︱Dimensions L x W x H 1500 x 1400 x 2600 mm︱Weight of machine approx. 2,5 t︱

---

Press capacity 60 t︱Stroke 400 mm︱Daylight 500 mm︱Table surface area 500 x 500 mm︱Approach speed 100 mm / s︱Working speed 10 mm / s︱Return speed 150 mm / s︱Dimensions L x W x H 1500 x 1400 x 2600 mm︱Weight of machine approx. 3,5 t︱

---

Press capacity 100 t︱Stroke 400 mm︱Daylight 500 mm︱Table surface area 800 x 500 mm︱Approach speed 100 mm / s︱Working speed 10 mm / s︱Return speed 160 mm / s︱Dimensions L x W x H 1600 x 1700 x 2930 mm︱Weight of machine approx. 5,5 t︱

---

Press capacity 50 t︱Throat depth 265 mm︱Stroke 250 mm︱Daylight 400 mm︱Table surface area 700 x 450 mm︱Approach speed 32 mm / s︱Working speed 6,3 mm / s︱Return speed 42 mm / s︱Dimensions L x W x H 1290 x 1160 x 2085 mm︱Weight of machine approx. 1,75 t︱

---

pressure 28 t︱throat 225 mm︱stroke 150 mm︱table surface area 325 x 300 mm︱work speed 2 - 9,8 mm/sek︱return speed 12,8 mm/sek︱total power requirement 4 kW︱weight of the machine ca. 650 kg︱dimensions of the machine ca. 1800 x 900 x 2000 mm︱

---

- NC control to adjust the piston stroke - Selector switch for manual or semi-automatic operation - Flow control valve and pressure control valve - Integrated pressure gauge - Various tools can be installed on the piston - inside There is a 40 mm hole for attaching the tools

pressure 160 t︱throat 350 mm︱stroke 140 mm︱dayligth 370 mm︱table surface area 750 x 620 mm︱hole in the table 220 mm︱table height over floor 850 mm︱ram surface 750 x 580 mm︱oil volume 700 l︱feed down 300 mm/sec︱feed up 480 mm/sec︱feed under pressure 58 mm/sec︱total power requirement 60 kW︱weight of the machine ca. 10,8 t︱required space 2,4 x 1,8 x 3,5 m︱

---

permitted for manual loading according to the German Safety Regulations (UVV) with oil-hydraulic drive, controllable two-hand operation 2020: new electrical (safety) control - Siemens S7-1500 F, easy operation via touch-panel Design of the electrical control according to DIN EN ISO 16092-1/-2/-3 year of manufacture 1995

pressure 100 t︱throat 360 mm︱stroke 600 mm︱dayligth 900 mm︱table surface area 1050 x 700 mm︱hole in the table 120 mm︱table height over floor 900 mm︱ram surface 800 x 600 mm︱oil volume 650 l︱total power requirement 30,0 kW︱weight of the machine ca. 11,0 t︱required space 1,8 x 2,8 x 3,6 m︱

---

permitted for manual loading according to the CE Regulations with oil-hydraulic drive, light-guard (Sick), two-hand operation WITH new electrical (safety) control - Siemens S7-1500 F, easy operation via touch-panel can be inspected in running condition in our warehouse

pressure 25 t︱throat 200 mm︱stroke 300 mm︱diameter of piston 100 mm︱piston rod diameter 70 mm︱ram speed, rapid traverse 137 mm/s︱ram speed, low pressure 67 mm/s︱ram speed, retracting movement 128 mm/s︱Setup speed, down max. 10 mm/s︱table height 900 mm︱oil volume ca. 250 l︱total power requirement 3 kW︱weight of the machine ca. 2,4 t︱dimensions of the machine ca. m︱

---

pressure 25 t︱stroke 150 mm︱throat 420 mm︱dayligth 450 mm︱table surface area 700 x 820 mm︱table height over floor 850 mm︱ram surface 600 x 600 mm︱feed down 370 mm/s︱feed up 370 mm/s︱working feed 18 - 33 mm/s︱oil volume 300 l︱power requirement 5,5 kW︱Weight 5,8 t︱dimensions of the machine ca. 1,1 x 2,0 x 2,4 mxmxm︱

---

permitted for manual loading according to the CE-norm with oil-hydraulic drive, controllable dependent on pressure/time and way, cutting impact cushioning, mechanical depth stop, two-hand operation

pressure 30 t︱throat max. 250 mm︱stroke max. 200 mm︱dayligth 475 mm︱table surface area 550 x 500 mm︱weight of the machine ca. 2050 kg︱power stroke 20 mm︱

---

pressure 40 t︱throat 300 mm︱stroke 630 mm︱dayligth 900 mm︱table surface area 620 x 520 mm︱hole in the table 150 mm︱table height over floor 600 mm︱ram surface 150 mm︱total power requirement 15,0 kW︱weight of the machine ca. 4,5 t︱required space 1,0 x 1,9 x 3,0 m︱

---

permitted for manual loading according to the CE Regulations with oil-hydraulic drive, controllable dependent on pressure/time and way, two-hand operation press can be inspected in running condition in our warehouse

pressure 40 t︱throat 300 mm︱stroke 630 mm︱dayligth 900 mm︱table surface area 620 x 520 mm︱hole in the table 150 mm︱table height over floor 600 mm︱ram surface 150 mm︱total power requirement 15,0 kW︱weight of the machine ca. 4,5 t︱required space 1,0 x 1,9 x 3,0 m︱

---

permitted for manual loading according to the CE Regulations with oil-hydraulic drive, controllable dependent on pressure/time and way, two-hand operation

pressure 40 t︱throat 330 mm︱stroke 250 mm︱dayligth 450 mm︱table surface area 800 x 500 mm︱hole in the table 100 mm︱table height over floor 900 mm︱ram surface 100 mm︱feed down 406 mm/sec︱feed up 393 mm/sec︱feed under pressure 14 mm/sec︱oil volume 350 l︱total power requirement 7,5 kW︱weight of the machine ca. 4,6 t︱required space 1,3 x 2,3 x 3,4 m︱

---

permitted for manual loading according to the CE Regulations with oil-hydraulic drive, controllable dependent on pressure/time and way, mechanical depth stop, two-hand operation press can be inspected in running condition in our warehouse

pressure 100 t︱throat 510 mm︱stroke 600 mm︱dayligth 1000 mm︱table surface area 1025 x 650 mm︱table height over floor 970 mm︱ram surface 1025 x 650 mm︱feed down 350 mm/sec︱feed up 330 mm/sec︱working feed 30 - 43 mm/sec︱oil volume 540 l︱total power requirement 48,0 kW︱weight of the machine ca. 12,0 t︱required space 1,2 x 2,7 x 3,9 m︱

---

permitted for manual loading according to the CE Regulations with oil-hydraulic drive

pressure 10 t︱throat 0 mm︱stroke 400 mm︱total power requirement 7,5 kW︱weight of the machine ca. 6500 t︱dimensions of the machine ca. m︱

---

D U N K E S (Germany) CNC Controlled Hydraulic Double Column Press Model HD 10 Year 1993 ________________________________________________________ Pressure 10 tons Ram stroke 400 mm Mounting height 600 mm Table size 400 x 300 mm Table height above floor 820 mm Ram area 400 x 300 mm Ram bore 40 mm Quickspeed, downwards, max. 70 mm/s Working speed, downwards, using max. pressure 40 mm/s Working speed, min. 5 mm/s Working speed adjustable from 5 - 70 mm/s Return stroke speed, min./max. 20 / 175 mm/s Drive 7.5 kW Total electrical load, approx. 12 kW - 380 V - 50 Hz Weight, approx. 6,500 kg Accessories / Special Features * DUNKES CNC Control, Model 200, can be programmed with presettable parameters, e.g. Stroke, speed, forward and return motion, pressing time, etc. * Separate switch cabinet with floppy disk input. * Pendant control with monitor. * Two-handed release, in conjunction with pneumatic safety door. * A turning device for calibrating and smoothing of bores is mounted on the ram. (Calibrating mandrel moves into the bore and rotates, powered by it own motor-driven timer. Repetitions are controlled by stroke counter.)

pressure 63 t︱stroke 160 mm︱throat 280 mm︱dayligth 360 mm︱table surface area 560 x 490 mm︱table height over floor 860 mm︱ram surface 280 x 280 mm︱oil volume l︱power requirement 22,0 kW︱Weight 3,6 t︱dimensions of the machine ca. 0,8 x 1,7 x 2,8 mxmxm︱hole in the table 125 mm︱

---

year of manufacture1980 Modernization of control 1993 permitted for manual loading according to the German Safety Regulations (UVV) with oil-hydraulic drive, controllable dependent on pressure/time and way, two-hand operation

pressure 2 x 6,3 t︱stroke 307 mm︱throat 180 mm︱dayligth 900 mm︱table surface area 470 x 360 mm︱die cushion capacity t︱die cushion stroke mm︱die cushion area mm︱table height over floor 810 mm︱ram surface 45 mm︱feed down 137 mm/s︱feed up 33 mm/s︱working feed 540 mm/s︱oil volume 140 l︱power requirement 3,0 kW︱Weight 1,5 t︱dimensions of the machine ca. 1,2 x 1,2 x 2,8 mxmxm︱

---

permitted for manual loading according to the CE-norm with oil-hydraulic drive, controllable dependent on pressure/time and way, two-hand operation Press has 2 Press shafts - press force 2 x 6,3 t

pressure 100 t︱throat 320 mm︱stroke 160 mm︱dayligth 480 mm︱table surface area 630 x 550 mm︱hole in the table 200 mm︱table height over floor 860 mm︱ram surface 560 x 450 mm︱oil volume 500 l︱total power requirement 30,5 kW︱weight of the machine ca. 6,4 t︱required space 1,6 x 2,0 x 2,9 m︱

---

year of manufacture 1979 overhaul 1993 permitted for manual loading according to the German Safety Regulations (UVV) with oil-hydraulic drive, controllable dependent on pressure/time and way, hydraulic cutting impact cushioning, mechanical depth stop, two-hand operation press can be inspected in running condition in our warehouse - can also be offered with new control on request

pressure 100 t︱throat 300 mm︱stroke 400 mm︱oil volume 300 l︱diameter of piston 200 mm︱piston speed, rapid traverse 121 mm/s︱piston speed, low pressure 60 mm/s︱piston speed, high pressure 9 mm/s︱piston speed, retracting movement 117 mm/s︱piston rod diameter 140 mm︱table surface area 740 x 580 mm︱table height over floor 900 mm︱ram surface 600 x 500 mm︱quantity of oil 300 l︱total power requirement 11 kW︱weight of the machine ca. 4,9 t︱dimensions of the machine ca. 1,0 x 1,76 x 2,52 m︱

---

pressure 75 t︱throat 280 mm︱stroke 303 mm︱total power requirement 15 kW︱weight of the machine ca. 7000 kg︱dimensions of the machine ca. m︱

---

pressure 6 t︱throat 120 mm︱stroke 80 mm︱Table length 280 mm︱Table width 200 mm︱

---

Pneumatic

pressure 160 t︱stroke 150 mm︱throat 370 mm︱dayligth 500 mm︱table surface area 1000 x 700 mm︱table height over floor 820 mm︱ram surface 600 x 520 mm︱feed down 350 mm/s︱feed up 350 mm/s︱working feed 12 - 36 mm/s︱oil volume 1100 l︱power requirement 27,0 kW︱Weight 16,5 t︱dimensions of the machine ca. 1,8 x 2,7 x 3,95 mxmxm︱hole in the table 100 mm︱

---

permitted for manual loading according to the German Safety Regulations (UVV) with oil-hydraulic drive, controllable dependent on pressure/time and way, cutting impact cushioning, depth stop (motoric adjustable), two-hand operation

pressure 30 t︱throat max. 250 mm︱stroke max. 200 mm︱power stroke 20 mm︱dayligth 475 mm︱table surface area 550 x 500 mm︱weight of the machine ca. 2050 kg︱

---
