          HANS - JÜRGEN GEIGER Maschinen-Vertrieb GmbH - Stockist for used machines

          Machinelist:


          Center Lathe

          used  Center Lathe COLCHESTER MASTIFF 1400


          • HANS - JÜRGEN GEIGER
          • James-Watt-Str. 12
          • 72555 Metzingen
          • Deutschland

          • (0049)-7123-18040
            (0049)-7123-18384
          • geiger@geiger-germany.com
            www.geiger-germany.com
          #1049-740219 · Center Lathe

          COLCHESTER - MASTIFF 1400 - - 1991 -

          Technical details
          turning diameter over bed 540 mm︱turning diameter over slide rest 370 mm︱turning length 1500 mm︱total power requirement 14 kW︱weight of the machine ca. 2.500 kg︱dimensions of the machine ca. m︱
          C O L C H E S T E R (GB) Universal Toolroom Lathe with 3-Axis Digital Read-Out FAGOR Model MASTIFF 1400 Year approx. 1991 S/Nr. LMF 60 GMRCG. 07597 _______________________________________________________ Height of centres 270 mm Max. swing dia. above bed 540 mm Max. swing dia. above slide 370 mm Max. swind dia over gap 815 mm Distance between centres 1,500 mm Spindle bore, approx. 88 mm 16 Spindle speeds 18 – 1.400 rpm Longitudinal feeds 0.06 – 1 mm/rev Facing feeds 0.03 – 0,5 mm/rev Metric threads 0.6 – 14 mm Whitworth threads 2 – 72 tpi Module threads 0.3 – 3,5 Mod. Diametral Pitches 8 – 60 D.P. Spindle drive 12 kW Total electrical load 14 kW - 380 V - 50 Hz Weight approx. 2,500 kg Accessories / Special Features: * Hardened and ground guideways. * Removable gap-part to increase the turning diameter in Front of Chuck * 3-Axis Digital Read-Out make FAGOR with tool management * Built –on 3-jaw chuck make DURO, Ø 315 mm, * PARAT Tool Holder Change System, with approx. 5 separate inserts. * Various centres, Drill Chuck for the tailstock * Chuck protection . * Coolant equipment with splash guard on backside and Chip collection tray * and various other accessories. Condition : Good, Machine can be inspected under power, ideal for tool room/repair shop Delivery : Ex stock, as inspected. Payment : Net, after conclusion of contract.
            turning diameter over bed 540 mm
            turning diameter over slide rest 370 mm
            turning length 1500 mm
            total power requirement 14 kW
            weight of the machine ca. 2.500 kg
            Description :
            C O L C H E S T E R (GB)
            Universal Toolroom Lathe with 3-Axis Digital Read-Out FAGOR
            Model MASTIFF 1400
            Year approx. 1991 S/Nr. LMF 60 GMRCG. 07597
            _______________________________________________________

            Height of centres 270 mm
            Max. swing dia. above bed 540 mm
            Max. swing dia. above slide 370 mm
            Max. swind dia over gap 815 mm

            Distance between centres 1,500 mm
            Spindle bore, approx. 88 mm
            16 Spindle speeds 18 – 1.400 rpm

            Longitudinal feeds 0.06 – 1 mm/rev
            Facing feeds 0.03 – 0,5 mm/rev

            Metric threads 0.6 – 14 mm
            Whitworth threads 2 – 72 tpi
            Module threads 0.3 – 3,5 Mod.
            Diametral Pitches 8 – 60 D.P.

            Spindle drive 12 kW
            Total electrical load 14 kW - 380 V - 50 Hz
            Weight approx. 2,500 kg

            Accessories / Special Features:

            * Hardened and ground guideways.
            * Removable gap-part to increase the turning diameter in Front of Chuck
            * 3-Axis Digital Read-Out make FAGOR with tool management
            * Built –on 3-jaw chuck make DURO, Ø 315 mm,
            * PARAT Tool Holder Change System, with approx. 5 separate inserts.
            * Various centres, Drill Chuck for the tailstock * Chuck protection .
            * Coolant equipment with splash guard on backside and Chip collection tray
            * and various other accessories.

            Condition : Good, Machine can be inspected under power,
            ideal for tool room/repair shop
            Delivery : Ex stock, as inspected.
            Payment : Net, after conclusion of contract.

          Datasheet
          Request / Contact
          used  Center Lathe COLCHESTER MASCOT 1600


          • HANS - JÜRGEN GEIGER
          • James-Watt-Str. 12
          • 72555 Metzingen
          • Deutschland

          • (0049)-7123-18040
            (0049)-7123-18384
          • geiger@geiger-germany.com
            www.geiger-germany.com
          #1049-693937 · Center Lathe

          COLCHESTER - MASCOT 1600 - - 1982 -

          Technical details
          turning diameter over bed 430 mm︱turning diameter over slide rest 260 mm︱turning length 1000 mm︱total power requirement 8 kW︱weight of the machine ca. 2.500 kg︱dimensions of the machine ca. m︱
            turning diameter over bed 430 mm
            turning diameter over slide rest 260 mm
            turning length 1000 mm
            total power requirement 8 kW
            weight of the machine ca. 2.500 kg
          Datasheet
          Request / Contact
          used  Center Lathe VDF BOEHRINGER V 800 x 4000


          • HANS - JÜRGEN GEIGER
          • James-Watt-Str. 12
          • 72555 Metzingen
          • Deutschland

          • (0049)-7123-18040
            (0049)-7123-18384
          • geiger@geiger-germany.com
            www.geiger-germany.com
          #1049-720724 · Center Lathe

          VDF BOEHRINGER - V 800 x 4000 - - 1974 -

          Technical details
          turning diameter over bed 820 mm︱turning diameter over slide rest 575 mm︱turning length 4000 mm︱total power requirement 30 kW︱weight of the machine ca. 7000 kg︱dimensions of the machine ca. m︱
            turning diameter over bed 820 mm
            turning diameter over slide rest 575 mm
            turning length 4000 mm
            total power requirement 30 kW
            weight of the machine ca. 7000 kg
          Datasheet
          Request / Contact
          used  Center Lathe VDF BOEHRINGER 44 S


          • HANS - JÜRGEN GEIGER
          • James-Watt-Str. 12
          • 72555 Metzingen
          • Deutschland

          • (0049)-7123-18040
            (0049)-7123-18384
          • geiger@geiger-germany.com
            www.geiger-germany.com
          #1049-677904 · Center Lathe

          VDF BOEHRINGER - 44 S - - 1970 -

          Technical details
          turning diameter over bed 450 mm︱turning diameter over slide rest 280 mm︱turning length 1000 mm︱total power requirement 8 kW︱weight of the machine ca. 2.500 kg︱dimensions of the machine ca. m︱
            turning diameter over bed 450 mm
            turning diameter over slide rest 280 mm
            turning length 1000 mm
            total power requirement 8 kW
            weight of the machine ca. 2.500 kg
          Datasheet
          Request / Contact
          used  Center Lathe VDF BOEHRINGER V 5 x 6000


          • HANS - JÜRGEN GEIGER
          • James-Watt-Str. 12
          • 72555 Metzingen
          • Deutschland

          • (0049)-7123-18040
            (0049)-7123-18384
          • geiger@geiger-germany.com
            www.geiger-germany.com
          #1049-656405 · Center Lathe

          VDF BOEHRINGER - V 5 x 6000 - - 1964 -

          Technical details
          turning diameter over bed 680 mm︱turning diameter over slide rest 480 mm︱turning length 6000 mm︱total power requirement 18 kW︱weight of the machine ca. 6000 kg︱dimensions of the machine ca. m︱
            turning diameter over bed 680 mm
            turning diameter over slide rest 480 mm
            turning length 6000 mm
            total power requirement 18 kW
            weight of the machine ca. 6000 kg
          Datasheet
          Request / Contact

          Chucking Automatic Lathe-Single Spindle

          used  Chucking Automatic Lathe-Single Spindle INDEX GS 30


          • HANS - JÜRGEN GEIGER
          • James-Watt-Str. 12
          • 72555 Metzingen
          • Deutschland

          • (0049)-7123-18040
            (0049)-7123-18384
          • geiger@geiger-germany.com
            www.geiger-germany.com
          #1049-453583 · Chucking Automatic Lathe-Single Spindle

          INDEX - GS 30 - - 1990 -

          Technical details
          turning diameter 60 mm︱turning length 200 mm︱number of slides ︱total power requirement 20 kW︱weight of the machine ca. t︱dimensions of the machine ca. m︱
            turning diameter 60 mm
            turning length 200 mm
            total power requirement 20 kW
          Datasheet
          Request / Contact

          CNC Lathe

          used  CNC Lathe EMAG VSC 250 DS


          • HANS - JÜRGEN GEIGER
          • James-Watt-Str. 12
          • 72555 Metzingen
          • Deutschland

          • (0049)-7123-18040
            (0049)-7123-18384
          • geiger@geiger-germany.com
            www.geiger-germany.com
          #1049-706038 · CNC Lathe

          EMAG - VSC 250 DS - - 2004 - SIEMENS 840 D

          Technical details
          turning diameter 250 mm︱turning length 100 mm︱control SIEMENS 840 D ︱total power requirement 35 kW︱weight of the machine ca. 7500 kg︱dimensions of the machine ca. m︱
          E M A G (Germany) Vertical CNC Controlled Hard Turning and Grinding machine with tool turret and workpiece handling System Model VSC 250 DS Year 2004 # M7 28.69324 _______________________________________________________ Turning Ø, max. 250 mm Turning length internal / external 100 mm Workpiece length min./max. 29 – 100 mm 6-positon tool turret Ø / swing-Ø 480/790 mm Workpiece spindle Slide travel, X / Z / stroke 680 / 400 / 200 mm Feed rate / Quick feed X/Z 45/30 m/min. Feed force X/Z 5,5/11 kN Spindle speed 4.300 / 6.000 rpm Spindle drive 28 kW Total electrical load, approx. 35 kW - 400 V - 50 Hz Weight, approx. 7,500 kg Accessories / Special Features: * CNC – Continuous Path Control SIEMENS Model 840 D, with colour monitor, graphics, menu-supervised dialogue programming, and all the usual options, cycles and subprograms, etc. * Hexagon Tool turret head with 6 tool positions (Ø 40 mm) without motorized tools posts, two positions T 3 u. T 6 equipped with grinding spindles with 42.000 rpm and with 18.000 rpm, using CBN discs resp. regular grinding tools * Workpiece handling device with WP transportation frames and circulation system and pick-up and unloading of finished parts directly through the motor spindle which is equipped with a hydraulic 3 jaws chuck make SMW Autobloc with membrane clamping and clamping control system. * MARPOSS MIDA Measuring Probe for measuring blank parts a. the finished parts * NORGREN air measuring system, hydraulic weight compensation of spindle, * Main elements of machine are temperature stabilized by a coolant system made by HYFRA * Recooler for the grinding coolant sitting on a large Coolant device consisting of SEITZ Paper Band filter and a mobile Chipconveyor, Magnetic separator, Centrallubrication, etc. Vertical CNC lathes offer a thermo-resistant construction (chips do not fall onto the machine bed),fast workpiece change times (pick-up system through the main spindle) and a ridged tool arrangement,which also allows unrelated machining work, like hard turning or grinding process on the same machine. Condition : Good. Machine can soon be inspected under power. Delivery : Ex stock, as inspected. Payment : Net, after conclusion of contract.
            turning diameter 250 mm
            turning length 100 mm
            control SIEMENS 840 D
            total power requirement 35 kW
            weight of the machine ca. 7500 kg
            Description :
            E M A G (Germany)
            Vertical CNC Controlled Hard Turning and Grinding machine
            with tool turret and workpiece handling System
            Model VSC 250 DS Year 2004 # M7 28.69324
            _______________________________________________________

            Turning Ø, max. 250 mm
            Turning length internal / external 100 mm
            Workpiece length min./max. 29 – 100 mm

            6-positon tool turret Ø / swing-Ø 480/790 mm

            Workpiece spindle Slide travel, X / Z / stroke 680 / 400 / 200 mm
            Feed rate / Quick feed X/Z 45/30 m/min.
            Feed force X/Z 5,5/11 kN
            Spindle speed 4.300 / 6.000 rpm

            Spindle drive 28 kW
            Total electrical load, approx. 35 kW - 400 V - 50 Hz
            Weight, approx. 7,500 kg

            Accessories / Special Features:

            * CNC – Continuous Path Control SIEMENS Model 840 D, with colour monitor,
            graphics, menu-supervised dialogue programming, and all the usual
            options, cycles and subprograms, etc.
            * Hexagon Tool turret head with 6 tool positions (Ø 40 mm) without
            motorized tools posts, two positions T 3 u. T 6 equipped with grinding
            spindles with 42.000 rpm and with 18.000 rpm, using CBN discs resp.
            regular grinding tools
            * Workpiece handling device with WP transportation frames and circulation
            system and pick-up and unloading of finished parts directly through the
            motor spindle which is equipped with a hydraulic 3 jaws chuck make SMW
            Autobloc with membrane clamping and clamping control system.
            * MARPOSS MIDA Measuring Probe for measuring blank parts a. the
            finished parts
            * NORGREN air measuring system, hydraulic weight compensation of spindle,
            * Main elements of machine are temperature stabilized by a coolant system
            made by HYFRA
            * Recooler for the grinding coolant sitting on a large Coolant device
            consisting of SEITZ Paper Band filter and a mobile Chipconveyor,
            Magnetic separator, Centrallubrication, etc.

            Vertical CNC lathes offer a thermo-resistant construction (chips do not fall
            onto the machine bed),fast workpiece change times (pick-up system through
            the main spindle) and a ridged tool arrangement,which also allows unrelated
            machining work, like hard turning or grinding process on the same machine.

            Condition : Good. Machine can soon be inspected under power.
            Delivery : Ex stock, as inspected.
            Payment : Net, after conclusion of contract.

          Datasheet
          Request / Contact
          used  CNC Lathe INDEX G 200


          • HANS - JÜRGEN GEIGER
          • James-Watt-Str. 12
          • 72555 Metzingen
          • Deutschland

          • (0049)-7123-18040
            (0049)-7123-18384
          • geiger@geiger-germany.com
            www.geiger-germany.com
          #1049-705010 · CNC Lathe

          INDEX - G 200 - - 1998 - SIEMENS SINUMERIC 840 C

          Technical details
          turning diameter 200 mm︱turning length 400 mm︱control SIEMENS SINUMERIC 840 C ︱total power requirement 40 kW︱weight of the machine ca. 6.500 kg︱dimensions of the machine ca. m︱
            turning diameter 200 mm
            turning length 400 mm
            control SIEMENS SINUMERIC 840 C
            total power requirement 40 kW
            weight of the machine ca. 6.500 kg
          Datasheet
          Request / Contact
          used  CNC Lathe HARDINGE CONQUEST T 42 SP


          • HANS - JÜRGEN GEIGER
          • James-Watt-Str. 12
          • 72555 Metzingen
          • Deutschland

          • (0049)-7123-18040
            (0049)-7123-18384
          • geiger@geiger-germany.com
            www.geiger-germany.com
          #1049-503166 · CNC Lathe

          HARDINGE - CONQUEST T 42 SP - - 1997 - FANUC 18 T

          Technical details
          turning diameter 150 mm︱turning length 300 mm︱control FANUC 18 T ︱total power requirement 22 kW︱weight of the machine ca. 7,5 t︱dimensions of the machine ca. m︱
          H A R D I N G E (USA) CNC High Precision Hard Turning Machine Model CONQUJEST T 42 SP = Super Precision Year 1997 _____________________________________________________________ Swing Ø above slide, max. approx. 300 mm Max. Workpiece Size using collet chuck Ø x Length 140 x 270 mm Max. Turning Length approx. 300 mm Spindle bore 48 mm Material admission 42 mm Spindle speeds, infinitely variable 60 - 6,000 rpm Turret: 12-position for square shaped Cutting Tool tips 25 x 25 mm and for shaft shaped cutting Tools VDI 30 with some toolholders mounted on the outer diameter of the turret Turret slide travel, longitudinal Z Axis / cross X Axis 380 / 190 mm Feed speeds, Z / X / Y 38 / 28 m/min Feed power, Z / X / Y 6,5 / 5 kN Tool holder shank square / round 25 / 32 mm Indexing time from station to station 0.36 sec Sub Spindle Head Spindle bore / spindle nose 42 mm Synchronized spindle speeds 60 - 6.000 mm Feed rates for Z / X - axis 38/28 m/min. Feed Torque Rate Z/X/Y 6,5/5 kN Spindle drive 11/7,5 kW Total electrical load, approx. 23 kW - 400 V - 50 Hz Weight 7,500 kg Accessories / Special Features * FANUC CNC Control in 2 axes, Model 18 T, with colour monitor and all of the usual multi-tasking functions, graphics, cycles and subprograms, etc. * The Main spindle is equipped with a Quick Change Collet Divice, prepared for the automatic loading and unloading of Workpieces * Equipped with a SUB SPINDLE opposite of main spindle allows end working on workpieces * 12-Station Turret Head with some toolholders - but no live tools * Built in chip conveyor, Ampere meter for main and sub spindle outside on the control panel * Optical adjustment device for exact tool setting, Lockable sliding doors, CE Sign, and * PROMOT Automatic Gantry Type Workpiece Loading System, Model COMPACT S 200 with 3 Axis and own SIEMENS CNC - Control connected to the Machine's CNC Control system consisting of Dual gripper-slide for unloading/loading process and WP-Supply system for raw and unfinished parts. Condition : Good to very good. Machine can be inspected under power. Due to the stiff HARCRETE-reinforced Cast iron base, the high axes resolution of 0.0001 mm and the high accurate main spindle bearings the machine is capable to replace the grinding process. Delivery : Ex stock, as inspected. Payment : Net, after conclusion of contract. Thank you for your interest.
            turning diameter 150 mm
            turning length 300 mm
            control FANUC 18 T
            total power requirement 22 kW
            weight of the machine ca. 7,5 t
            Description :
            H A R D I N G E (USA)
            CNC High Precision Hard Turning Machine
            Model CONQUJEST T 42 SP = Super Precision
            Year 1997
            _____________________________________________________________

            Swing Ø above slide, max. approx. 300 mm
            Max. Workpiece Size using collet chuck Ø x Length 140 x 270 mm
            Max. Turning Length approx. 300 mm
            Spindle bore 48 mm
            Material admission 42 mm
            Spindle speeds, infinitely variable 60 - 6,000 rpm

            Turret: 12-position for square shaped Cutting Tool tips 25 x 25 mm and
            for shaft shaped cutting Tools VDI 30 with some toolholders mounted on the
            outer diameter of the turret
            Turret slide travel, longitudinal Z Axis / cross X Axis 380 / 190 mm
            Feed speeds, Z / X / Y 38 / 28 m/min
            Feed power, Z / X / Y 6,5 / 5 kN
            Tool holder shank square / round 25 / 32 mm
            Indexing time from station to station 0.36 sec

            Sub Spindle Head
            Spindle bore / spindle nose 42 mm
            Synchronized spindle speeds 60 - 6.000 mm

            Feed rates for Z / X - axis 38/28 m/min.
            Feed Torque Rate Z/X/Y 6,5/5 kN

            Spindle drive 11/7,5 kW
            Total electrical load, approx. 23 kW - 400 V - 50 Hz
            Weight 7,500 kg

            Accessories / Special Features
            * FANUC CNC Control in 2 axes, Model 18 T, with colour monitor and all of the usual
            multi-tasking functions, graphics, cycles and subprograms, etc.
            * The Main spindle is equipped with a Quick Change Collet Divice, prepared for the automatic
            loading and unloading of Workpieces
            * Equipped with a SUB SPINDLE opposite of main spindle allows end working on workpieces
            * 12-Station Turret Head with some toolholders - but no live tools
            * Built in chip conveyor, Ampere meter for main and sub spindle outside on the control panel
            * Optical adjustment device for exact tool setting, Lockable sliding doors, CE Sign, and

            * PROMOT Automatic Gantry Type Workpiece Loading System, Model COMPACT S 200 with 3 Axis and own SIEMENS CNC - Control connected to the Machine's CNC Control system consisting of Dual gripper-slide for unloading/loading process and WP-Supply system for raw and unfinished parts.


            Condition : Good to very good. Machine can be inspected under power. Due to the stiff HARCRETE-reinforced Cast iron base, the high axes resolution of 0.0001 mm and the high accurate main spindle bearings the machine is capable to replace the grinding process.
            Delivery : Ex stock, as inspected.
            Payment : Net, after conclusion of contract.

            Thank you for your interest.

          Datasheet
          Request / Contact
          used  CNC Lathe INDEX GSC 65


          • HANS - JÜRGEN GEIGER
          • James-Watt-Str. 12
          • 72555 Metzingen
          • Deutschland

          • (0049)-7123-18040
            (0049)-7123-18384
          • geiger@geiger-germany.com
            www.geiger-germany.com
          #1049-279545 · CNC Lathe

          INDEX - GSC 65 - - 1991 - C 200 / 8

          Technical details
          turning diameter 250 mm︱turning length 400 mm︱control C 200 / 8 ︱total power requirement 60 kW︱weight of the machine ca. 8,5 t︱
          Swing Ø above bed, max. 300 mm Max. turning Ø for chucking work, approx. 250 mm Travel of Slides: Turret 1, X / Z travel 163 / 550 mm Turret 2, X / Z / Y travel 140 / 250 / 260 mm Spindle bore, approx. 65 mm Tool holder bore 30 mm Spindle speeds 25 - 5,000 rpm Feed range 0 - 15,000 rpm Spindle drive 0.5 - 40 kW Total electrical load 60 kW - 380 V - 50 Hz Weight, approx. 8,500 kg Accessories / Special Features * SIEMENS CNC Continuous Path Control, Model 880 (INDEX C 200-8) for at least 6 axes, with enlarged memory and with subprograms, simulation, etc. * Double column loading device for large workpieces, mounted above the machine. With 3-jaw gripper and storage system for blanks and finished parts, integrated in the CNC control. * Spindle indexing and positioning device, 7.5°. * Hydraulic high-power chuck (hollow clamping cylinder Ø 65 mm). Manufacturer: ROHM, Model HS 200/3-66, and ROHM Power Chuck, Model KFD HS 137 in the opposed spindle. * Driven tools in Turrets 1, 2 and 3, drive approx. 6 kW each. Tool stations: 8 / 12 / 8 + 28 tools in magazine = 55 tools altogether. * Tool measuring device for Turret 1. * Tool disk magazine for Revolver No. 2 with 28 tool positions and automatic tool changer. * Backwork is possible using the control unit for the 3rd turret. * Coolant device with large chip conveyor. * Automatic sliding doors. * Various other accessories. Price, ex stock EUR 49,000.-- Ideal machine for heavy and complex turned parts. Complete processing is possible, including backwork. Condition : Good to very good. Machine can be inspected under power. Delivery : Ex stock as inspected Payment : Net, after conclusion of contract Thank you for your interest. We have a selection of CNC lathes available. Please let us know your requirements
            turning diameter 250 mm
            turning length 400 mm
            control C 200 / 8
            total power requirement 60 kW
            weight of the machine ca. 8,5 t
            Description :
            Swing Ø above bed, max. 300 mm
            Max. turning Ø for chucking work, approx. 250 mm

            Travel of Slides:
            Turret 1, X / Z travel 163 / 550 mm
            Turret 2, X / Z / Y travel 140 / 250 / 260 mm

            Spindle bore, approx. 65 mm
            Tool holder bore 30 mm

            Spindle speeds 25 - 5,000 rpm
            Feed range 0 - 15,000 rpm

            Spindle drive 0.5 - 40 kW
            Total electrical load 60 kW - 380 V - 50 Hz
            Weight, approx. 8,500 kg

            Accessories / Special Features
            * SIEMENS CNC Continuous Path Control, Model 880 (INDEX C 200-8) for at least 6 axes, with enlarged memory and with subprograms, simulation, etc.
            * Double column loading device for large workpieces, mounted above the machine. With 3-jaw gripper and storage system for blanks and finished parts, integrated in the CNC control.
            * Spindle indexing and positioning device, 7.5°.
            * Hydraulic high-power chuck (hollow clamping cylinder Ø 65 mm). Manufacturer: ROHM, Model HS 200/3-66, and ROHM Power Chuck, Model KFD HS 137 in the opposed spindle.
            * Driven tools in Turrets 1, 2 and 3, drive approx. 6 kW each. Tool stations: 8 / 12 / 8 + 28 tools in magazine = 55 tools altogether.
            * Tool measuring device for Turret 1.
            * Tool disk magazine for Revolver No. 2 with 28 tool positions and automatic tool changer.
            * Backwork is possible using the control unit for the 3rd turret.
            * Coolant device with large chip conveyor. * Automatic sliding doors.
            * Various other accessories.

            Price, ex stock EUR 49,000.--

            Ideal machine for heavy and complex turned parts. Complete processing is possible, including backwork.

            Condition : Good to very good. Machine can be inspected under power.
            Delivery : Ex stock as inspected
            Payment : Net, after conclusion of contract

            Thank you for your interest.
            We have a selection of CNC lathes available. Please let us know your requirements
          Datasheet
          Request / Contact
          used  CNC Lathe GILDEMEISTER GAC 42


          • HANS - JÜRGEN GEIGER
          • James-Watt-Str. 12
          • 72555 Metzingen
          • Deutschland

          • (0049)-7123-18040
            (0049)-7123-18384
          • geiger@geiger-germany.com
            www.geiger-germany.com
          #1049-333531 · CNC Lathe

          GILDEMEISTER - GAC 42 - - 1991 -

          Technical details
          turning diameter 42 mm︱turning length 250 mm︱control ︱total power requirement kW︱weight of the machine ca. t︱dimensions of the machine ca. m︱
          CNC-lathe with bar feed with Sameca bar feed
            turning diameter 42 mm
            turning length 250 mm
            Description :
            CNC-lathe with bar feed
            with Sameca bar feed
          Datasheet
          Request / Contact
          used  CNC Lathe TRAUB TNS 65/ 80 D


          • HANS - JÜRGEN GEIGER
          • James-Watt-Str. 12
          • 72555 Metzingen
          • Deutschland

          • (0049)-7123-18040
            (0049)-7123-18384
          • geiger@geiger-germany.com
            www.geiger-germany.com
          #1049-346509 · CNC Lathe

          TRAUB - TNS 65/ 80 D - - 1990 - TX8D

          Technical details
          turning diameter 250 mm︱turning length 450 mm︱control TX8D ︱bore 80 mm︱spindle speed: 3150 U/min.︱
          CNC Lathe with Bar Feed and 3 Turrets Very large spindle bore, with bar loading device Please ask for further details.
            turning diameter 250 mm
            turning length 450 mm
            control TX8D
            bore 80 mm
            spindle speed: 3150 U/min.
            Description :
            CNC Lathe with Bar Feed and 3 Turrets
            Very large spindle bore, with bar loading device

            Please ask for further details.
          Datasheet
          Request / Contact

          CNC Lathe - Inclined Bed Type

          used  CNC Lathe - Inclined Bed Type HEYLIGENSTAEDT HEYNUMAT 24 U 5000


          • HANS - JÜRGEN GEIGER
          • James-Watt-Str. 12
          • 72555 Metzingen
          • Deutschland

          • (0049)-7123-18040
            (0049)-7123-18384
          • geiger@geiger-germany.com
            www.geiger-germany.com
          #1049-609974 · CNC Lathe - Inclined Bed Type

          HEYLIGENSTAEDT - HEYNUMAT 24 U 5000 - - 1990 - SIEMENS Sinumerik 3 T

          Technical details
          turning diameter 900 mm︱turning length 5000 mm︱control SIEMENS Sinumerik 3 T ︱total power requirement 85 kW︱weight of the machine ca. 22 t︱dimensions of the machine ca. m︱
            turning diameter 900 mm
            turning length 5000 mm
            control SIEMENS Sinumerik 3 T
            total power requirement 85 kW
            weight of the machine ca. 22 t
          Datasheet
          Request / Contact

          CNC-Vertical Turret Lathe - Single Col.

          used  CNC-Vertical Turret Lathe - Single Col. PITTLER PV 1250 1-1


          • HANS - JÜRGEN GEIGER
          • James-Watt-Str. 12
          • 72555 Metzingen
          • Deutschland

          • (0049)-7123-18040
            (0049)-7123-18384
          • geiger@geiger-germany.com
            www.geiger-germany.com
          #1049-447347 · CNC-Vertical Turret Lathe - Single Col.

          PITTLER - PV 1250 1-1 - - 1994 -

          Technical details
          turning diameter 1250 mm︱swing diameter 1160 mm︱turning height 800 mm︱faceplate diameter 1000 mm︱total power requirement 97 kW︱weight of the machine ca. 25000 t︱dimensions of the machine ca. m︱
          P I T T L E R (Germany) CNC Controlled Vertical Turning and Milling Centre With Tool Changer and Pallet Changer Model PV 1250 / 1-1 Year 1994 _______________________________________________________ Turning Ø max. 1,000 mm Swing Ø max. 1,160 mm Turning length 800 mm X Axis - horizontal 1,300 mm Y Axis - vertical 800 mm Feed / quick feed 16,000 mm/min Main spindle speeds 10 - 1,000 rpm ! Main spindle speeds via separate C Axis 0.1 - 16 rpm Positioning accuracy of C Axis 360° + / - 5 " Tool holder ISO 50 Tool drive 22 kW Max. torque / spindle speed 315 Nm / 2,500 rpm Pallet size 630 x 630 mm Spindle drive 63 kW Total electrical load 97 kW - 400 V - 50 Hz Weight, approx. 25,000 kg Accessories / Special Features * CNC Contouring Control Model NUM 760 TX in 3 axes, with graphics, menu-guided dialogue programming, and all the usual options, cycles and sub-programs; with tool compensation, thread cutting cycles, constant speed programming, etc. * 2-axis CNC tool slide (1,300 x 800 mm) with driven tool holders, ISA 50 / 22 kW. * Tool changer with 16 tool holders, max. length 450 mm, max. weight 40 kg. * Pallet changing system, pallet size 630 x 630 mm, with setup station with indexing and drive of the pallet, and 2 separate pallet stations. * 3 pallets, 630 x 630 mm. * 3-jaw chuck, Ø 650 mm. * Face plate, Ø 900 mm. * Chip conveyor. * Band filter coolant equipment. * Completely covered working area, including safety fence for the pallet changing area. * Separate switch cabinet. * Operating manual. * Approx. 20 tool holders. * Various other accessories. High performance universal turning and milling centre for full range of machining (turning, boring, drilling, milling, and threading) with high speeds and high turning volume. Condition : Good to very good. Machine can soon be inspected under power. Delivery : Ex stock as inspected Payment : Net, after conclusion of contract Thank you for your interest. We have a selection of modern lathes available. Please let us know your requirements
            turning diameter 1250 mm
            swing diameter 1160 mm
            turning height 800 mm
            faceplate diameter 1000 mm
            total power requirement 97 kW
            weight of the machine ca. 25000 t
            Description :
            P I T T L E R (Germany)
            CNC Controlled Vertical Turning and Milling Centre
            With Tool Changer and Pallet Changer
            Model PV 1250 / 1-1 Year 1994
            _______________________________________________________
            Turning Ø max. 1,000 mm
            Swing Ø max. 1,160 mm
            Turning length 800 mm

            X Axis - horizontal 1,300 mm
            Y Axis - vertical 800 mm
            Feed / quick feed 16,000 mm/min

            Main spindle speeds 10 - 1,000 rpm !
            Main spindle speeds via separate C Axis 0.1 - 16 rpm
            Positioning accuracy of C Axis 360° + / - 5 "

            Tool holder ISO 50
            Tool drive 22 kW
            Max. torque / spindle speed 315 Nm / 2,500 rpm

            Pallet size 630 x 630 mm

            Spindle drive 63 kW
            Total electrical load 97 kW - 400 V - 50 Hz
            Weight, approx. 25,000 kg

            Accessories / Special Features
            * CNC Contouring Control Model NUM 760 TX in 3 axes, with graphics, menu-guided dialogue programming, and all the usual options, cycles and sub-programs; with tool compensation, thread cutting cycles, constant speed programming, etc.
            * 2-axis CNC tool slide (1,300 x 800 mm) with driven tool holders, ISA 50 / 22 kW.
            * Tool changer with 16 tool holders, max. length 450 mm, max. weight 40 kg.
            * Pallet changing system, pallet size 630 x 630 mm, with setup station with indexing and drive of the pallet, and 2 separate pallet stations.
            * 3 pallets, 630 x 630 mm. * 3-jaw chuck, Ø 650 mm. * Face plate, Ø 900 mm.
            * Chip conveyor. * Band filter coolant equipment. * Completely covered working area, including safety fence for the pallet changing area. * Separate switch cabinet. * Operating manual.
            * Approx. 20 tool holders. * Various other accessories.


            High performance universal turning and milling centre for full range of machining (turning, boring, drilling, milling, and threading) with high speeds and high turning volume.

            Condition : Good to very good. Machine can soon be inspected under power.
            Delivery : Ex stock as inspected
            Payment : Net, after conclusion of contract

            Thank you for your interest.
            We have a selection of modern lathes available. Please let us know your requirements

          Datasheet
          Request / Contact

          Facing Lathe

          used  Facing Lathe RAVENSBURG K 900 KH


          • HANS - JÜRGEN GEIGER
          • James-Watt-Str. 12
          • 72555 Metzingen
          • Deutschland

          • (0049)-7123-18040
            (0049)-7123-18384
          • geiger@geiger-germany.com
            www.geiger-germany.com
          #1049-18011 · Facing Lathe

          RAVENSBURG - K 900 KH - - 1966 -

          Technical details
          faceplate diameter 0 mm︱turning diameter over slide rest 900 mm︱turning length 1.000 mm︱total power requirement 25 kW︱weight of the machine ca. 8 t︱dimensions of the machine ca. m︱
          Height of centres 550 mm Max. turning Æ 1200 mm Max. turning Æ over slides, approx. 900 mm Max. turning length, approx. 1000 mm Spindle bore, approx. 90 mm 24 spindle speeds 4.3 - 587 rpm Feeds, infinitely variable 1 - 170 mm/min Total load, approx. 25 kW - 380 V - 50 Hz Weight, approx. 8000 kg Accessories/specialities Two separate slides, each equipped with 2-coordinate copying equipment, program controlled by plugboard, strengthened bearings and spindle, hardened and ground guideways, FORKHARDT 3-jaw chuck/ face plate, separate switch cabinet and cooling equipment. This machine is suitable for complicated, high precision copying of heavy workpieces.
            turning diameter over slide rest 900 mm
            turning length 1.000 mm
            total power requirement 25 kW
            weight of the machine ca. 8 t
            Description :
            Height of centres 550 mm
            Max. turning Æ 1200 mm
            Max. turning Æ over slides, approx. 900 mm
            Max. turning length, approx. 1000 mm
            Spindle bore, approx. 90 mm
            24 spindle speeds 4.3 - 587 rpm
            Feeds, infinitely variable 1 - 170 mm/min
            Total load, approx. 25 kW - 380 V - 50 Hz
            Weight, approx. 8000 kg

            Accessories/specialities
            Two separate slides, each equipped with 2-coordinate copying
            equipment, program controlled by plugboard, strengthened bearings
            and spindle, hardened and ground guideways, FORKHARDT 3-jaw chuck/
            face plate, separate switch cabinet and cooling equipment.
            This machine is suitable for complicated, high precision copying
            of heavy workpieces.
          Datasheet
          Request / Contact

          Lathe - cycle-controlled

          used  Lathe -  cycle-controlled MONFORTS KNC 5 S 3000


          • HANS - JÜRGEN GEIGER
          • James-Watt-Str. 12
          • 72555 Metzingen
          • Deutschland

          • (0049)-7123-18040
            (0049)-7123-18384
          • geiger@geiger-germany.com
            www.geiger-germany.com
          #1049-669430 · Lathe - cycle-controlled

          MONFORTS - KNC 5 S 3000 - - 1996 - MONFORTS CONTROL MTC-K

          Technical details
          turning diameter 580 mm︱turning length 3.000 mm︱control MONFORTS CONTROL MTC-K ︱total power requirement 17 kW︱weight of the machine ca. 6.300 kg︱dimensions of the machine ca. m︱
            turning diameter 580 mm
            turning length 3.000 mm
            control MONFORTS CONTROL MTC-K
            total power requirement 17 kW
            weight of the machine ca. 6.300 kg
          Datasheet
          Request / Contact
          used  Lathe -  cycle-controlled SOMAB UNIMAB 400


          • HANS - JÜRGEN GEIGER
          • James-Watt-Str. 12
          • 72555 Metzingen
          • Deutschland

          • (0049)-7123-18040
            (0049)-7123-18384
          • geiger@geiger-germany.com
            www.geiger-germany.com
          #1049-695990 · Lathe - cycle-controlled

          SOMAB - UNIMAB 400 - - 1996 - NUM Type 1062 T

          Technical details
          turning diameter 400 mm︱turning length 915 mm︱control NUM Type 1062 T ︱total power requirement 12,5 kW︱weight of the machine ca. 5500 kg︱dimensions of the machine ca. m︱
            turning diameter 400 mm
            turning length 915 mm
            control NUM Type 1062 T
            total power requirement 12,5 kW
            weight of the machine ca. 5500 kg
          Datasheet
          Request / Contact
          used  Lathe -  cycle-controlled KERN CD 320


          • HANS - JÜRGEN GEIGER
          • James-Watt-Str. 12
          • 72555 Metzingen
          • Deutschland

          • (0049)-7123-18040
            (0049)-7123-18384
          • geiger@geiger-germany.com
            www.geiger-germany.com
          #1049-737786 · Lathe - cycle-controlled

          KERN - CD 320 - - 1996 - GRUNDIG Manual Plus

          Technical details
          turning diameter 320 mm︱turning length 750 mm︱control GRUNDIG Manual Plus ︱total power requirement 18 kW︱weight of the machine ca. 2000 kg︱dimensions of the machine ca. m︱
            turning diameter 320 mm
            turning length 750 mm
            control GRUNDIG Manual Plus
            total power requirement 18 kW
            weight of the machine ca. 2000 kg
          Datasheet
          Request / Contact

          lathe-conventional-electronic

          used  lathe-conventional-electronic GILDEMEISTER NEF  320 K


          • HANS - JÜRGEN GEIGER
          • James-Watt-Str. 12
          • 72555 Metzingen
          • Deutschland

          • (0049)-7123-18040
            (0049)-7123-18384
          • geiger@geiger-germany.com
            www.geiger-germany.com
          #1049-751948 · lathe-conventional-electronic

          GILDEMEISTER - NEF 320 K - - 2001 -

          Technical details
          turning diameter 320 mm︱turning length 750 mm︱swing diameter over bed slide 150 mm︱total power requirement 10 kW︱weight of the machine ca. 2000 kg︱dimensions of the machine ca. m︱
            turning diameter 320 mm
            turning length 750 mm
            swing diameter over bed slide 150 mm
            total power requirement 10 kW
            weight of the machine ca. 2000 kg
          Datasheet
          Request / Contact

          Turning Automatic Lathe - swiss lathe

          used  Turning Automatic Lathe - swiss lathe TORNOS ENC 264


          • HANS - JÜRGEN GEIGER
          • James-Watt-Str. 12
          • 72555 Metzingen
          • Deutschland

          • (0049)-7123-18040
            (0049)-7123-18384
          • geiger@geiger-germany.com
            www.geiger-germany.com
          #1049-353545 · Turning Automatic Lathe - swiss lathe

          TORNOS - ENC 264 - - 1995 -

          Technical details
          turning diameter over bed 50 mm︱spindle passage 26 mm︱turning length 275 mm︱total power requirement 12 kW︱weight of the machine ca. 4500 kg︱
          CNC-Sliding Headstock Lathe, Opposite Headstock
            turning diameter over bed 50 mm
            spindle passage 26 mm
            turning length 275 mm
            total power requirement 12 kW
            weight of the machine ca. 4500 kg
            Description :
            CNC-Sliding Headstock Lathe, Opposite Headstock
          Datasheet
          Request / Contact

          Deephole Boring Machine

          used  Deephole Boring Machine TBT BWP 250


          • HANS - JÜRGEN GEIGER
          • James-Watt-Str. 12
          • 72555 Metzingen
          • Deutschland

          • (0049)-7123-18040
            (0049)-7123-18384
          • geiger@geiger-germany.com
            www.geiger-germany.com
          #1049-410847 · Deephole Boring Machine

          TBT - BWP 250 - - 1996 -

          Technical details
          core drilling diameter max. 25 mm︱bore depth 1000 mm︱swing diameter mm︱total power requirement 25 kW︱weight of the machine ca. 12,5 t︱dimensions of the machine ca. m︱
          T B T (Germany) CNC-Controlled Horizontal Deep Hole Drilling " Centre " Model BWP 250 Year 1996, but reconditioned mechanically and electrically in 2006 ___________________________________________________________________________________ Working range: X Axis, machine column cross 2,000 mm Z Axis, drilling slide horizontal 1,200 mm Drilling depth 1.000 mm Y Axis, drilling slide vertical 1,100 mm Table clamping area 1,200 x 2,000 mm Drilling capacity in solid material, approx. 4 - 25 mm Tool holder taper HSK 50 Spindle speeds 1.260 - 15,000 rpm Feed rates / quickfeed, XYZ, infinitely variable 100 - 10,000/15.000 mm/min. Force rate of feed motors 27 Nm / 1.000 daN Spindle drive steplessly adjustable 7 kW Total electrical load, approx. 30 kW - 400 V - 50 Hz Weight, approx. 10,000 kg Accessories / Special Features: " Ideal machine for the complete processing of large workpieces like tool a. dies (cooling holes) mould- and dieplates, hydraulicparts etc. by means of deep hole drilling up to 25 x 1.000 mm, face milling up to Ø 60 mm, spiral twist drilling, counterboring and threading up to M 24 x 3 mm. " SIEMENS Continuous Path Control in 4 axes Model 840 D, with process monitoring for coolant pressure, operation data control function, toollife, feed force,Error diagnostics and easy dialogueprogramming directly on the panel, etc. " High Frequency Spindle Make GAMFIOR with stepless speeds " Hydraulically movable drill bush carrier, swivels 90° for holding gun drills (ELB) or picking up regular tools from the tool changer like twist drills, milling tools, taps, etc. " With automatic tool changer made by MIKSCH, Model CTM 40, using a 12-position tool changer, which is mounted on the r.h.side of machine housing, in fixed position, only moving forward and backward for tool changing operation. " Built-on indexing table as B-Axis made by FIBRO Model RTN 400 = 420 x 420 mm, " Extra Rotary Table made by FIBRO with Ø 1.000mm, for indexing 3-144 positions " Built-in coolant device with chip conveyor and various filters. " 2 steady rests. " Completely covered working area with access at the front and at the side. Condition : Very good condition. This is a rare and valuable machine. Under Power Delivery : immediately ex our Stock Payment : Net, after conclusion of contract.
            core drilling diameter max. 25 mm
            bore depth 1000 mm
            total power requirement 25 kW
            weight of the machine ca. 12,5 t
            Description :
            T B T (Germany)
            CNC-Controlled Horizontal Deep Hole Drilling " Centre "
            Model BWP 250
            Year 1996, but reconditioned mechanically and electrically in 2006
            ___________________________________________________________________________________

            Working range: X Axis, machine column cross 2,000 mm
            Z Axis, drilling slide horizontal 1,200 mm
            Drilling depth 1.000 mm
            Y Axis, drilling slide vertical 1,100 mm

            Table clamping area 1,200 x 2,000 mm

            Drilling capacity in solid material, approx. 4 - 25 mm
            Tool holder taper HSK 50
            Spindle speeds 1.260 - 15,000 rpm

            Feed rates / quickfeed, XYZ,
            infinitely variable 100 - 10,000/15.000 mm/min.
            Force rate of feed motors 27 Nm / 1.000 daN

            Spindle drive steplessly adjustable 7 kW
            Total electrical load, approx. 30 kW - 400 V - 50 Hz
            Weight, approx. 10,000 kg

            Accessories / Special Features:

            " Ideal machine for the complete processing of large workpieces like tool a. dies (cooling holes) mould- and dieplates, hydraulicparts etc. by means of deep hole drilling up to 25 x 1.000 mm, face milling up to Ø 60 mm, spiral twist drilling, counterboring and threading up to M 24 x 3 mm.
            " SIEMENS Continuous Path Control in 4 axes Model 840 D, with process monitoring for coolant pressure, operation data control function, toollife, feed force,Error diagnostics and easy dialogueprogramming directly on the panel, etc.
            " High Frequency Spindle Make GAMFIOR with stepless speeds
            " Hydraulically movable drill bush carrier, swivels 90° for holding gun drills (ELB) or picking up regular tools from the tool changer like twist drills, milling tools, taps, etc.
            " With automatic tool changer made by MIKSCH, Model CTM 40, using a 12-position tool changer, which is mounted on the r.h.side of machine housing, in fixed position, only moving forward and backward for tool changing operation.
            " Built-on indexing table as B-Axis made by FIBRO Model RTN 400 = 420 x 420 mm,
            " Extra Rotary Table made by FIBRO with Ø 1.000mm, for indexing 3-144 positions
            " Built-in coolant device with chip conveyor and various filters.
            " 2 steady rests.
            " Completely covered working area with access at the front and at the side.

            Condition : Very good condition. This is a rare and valuable machine. Under Power
            Delivery : immediately ex our Stock
            Payment : Net, after conclusion of contract.
          Datasheet
          Request / Contact
          used  Deephole Boring Machine TBT HS 1-350


          • HANS - JÜRGEN GEIGER
          • James-Watt-Str. 12
          • 72555 Metzingen
          • Deutschland

          • (0049)-7123-18040
            (0049)-7123-18384
          • geiger@geiger-germany.com
            www.geiger-germany.com
          #1049-469994 · Deephole Boring Machine

          TBT - HS 1-350 - - 1990 -

          Technical details
          core drilling diameter max. 6 mm︱bore depth 350 mm︱swing diameter mm︱total power requirement 15 kW︱weight of the machine ca. 3500 kg︱dimensions of the machine ca. 5000 x 1200 x 2200 mm︱
            core drilling diameter max. 6 mm
            bore depth 350 mm
            total power requirement 15 kW
            weight of the machine ca. 3500 kg
            dimensions of the machine ca. 5000 x 1200 x 2200 mm
          Datasheet
          Request / Contact
          used  Deephole Boring Machine GILDEMEISTER & KNOLL 2 M 01-2-320


          • HANS - JÜRGEN GEIGER
          • James-Watt-Str. 12
          • 72555 Metzingen
          • Deutschland

          • (0049)-7123-18040
            (0049)-7123-18384
          • geiger@geiger-germany.com
            www.geiger-germany.com
          #1049-402623 · Deephole Boring Machine

          GILDEMEISTER & KNOLL - 2 M 01-2-320 - - 1985 -

          Technical details
          core drilling diameter max. 18 mm︱bore depth 320 mm︱swing diameter mm︱total power requirement 33 kW︱weight of the machine ca. 6 t︱dimensions of the machine ca. m︱
            core drilling diameter max. 18 mm
            bore depth 320 mm
            total power requirement 33 kW
            weight of the machine ca. 6 t
          Datasheet
          Request / Contact
          used  Deephole Boring Machine SIG B 30 /16


          • HANS - JÜRGEN GEIGER
          • James-Watt-Str. 12
          • 72555 Metzingen
          • Deutschland

          • (0049)-7123-18040
            (0049)-7123-18384
          • geiger@geiger-germany.com
            www.geiger-germany.com
          #1049-382093 · Deephole Boring Machine

          SIG - B 30 /16 - - 1965 -

          Technical details
          core drilling diameter max. 50 mm︱bore depth 2000 mm︱swing diameter mm︱drilling capacity diameter max. 110 mm︱total power requirement 30 kW︱weight of the machine ca. 10 t︱
          Drilling Ø, approx. 2 - 50 mm Boring Ø, approx. 100 mm Drilling depth, max. (see stroke / mounting length) 1,600 - 2,000 mm Stroke of drilling slide, approx. 4,000 mm Distance between the two spindle heads 5,000 mm Height of centres above guideways 350 / 450 mm Drilling feed of drilling slide, infinitely variable 20 - 200 mm/min Quick feed of drilling slide 2,500 mm/min Spindle speeds via belt disks 260 - 650 / 650 - 1,625 rpm Workspindle drive 24 kW Drive of coolant pumps 1 x 7.5/15 kW and 1 x 15/28 kW Total electrical load, approx. 60 kW - 380 V - 50 Hz Total length of machine / guideways 7,500 / 5,000 mm Weight, approx. 10,000 kg Accessories / Special Features * Machine consists of the following elements: Main spindle on the left-hand side, followed by the coolant oil supply device. Table group, driven by ball screw spindle. Coolant oil supply device with elevated height of centres. At the end is a headstock, Type B 16, with drive motor approx. 7.5 kW, n = 900/2400 and 2400/6000. Large coolant device with filter unit. Large selection of accessories and drilling tools with Ø up to 100 mm. * Machine is suitable for working with a rotating workpiece together with a fixed drilling tool (ELB and BTA Process), as well as for a fixed workpiece and a rotating drilling tool. It can work with internal oil feed (Elb) or with external oil feed (BTA). * Complete oil coolant unit with tank and filter and two SIG high pressure pumps. Number of litres can be set: 17 / 40 / 120 or 220 / 500 litres per minute. Capacity approx. 2,500 l. * Feed of main slide is via ball screw spindle and infinitely variable DC motor. Mounted on the main slide is at present a table, approx. 800 x 800 mm, cross-adjustable approx. 500 mm, and suitable for holding cubic and cylindrical workpieces. Electric control via cam rail, approx. 2,500 mm long. End switch for quick feed, feed and return. * 2 closed 3-point steady rests. * FORKHARDT 3-Jaw Chuck, manually operated, Ø approx. 315 mm. * Modernized control panel with speed display, feed setting and display, display for kW, switch for feed, quick feed, right/left, etc. * 2 separate switch cabinets, separate coolant oil display device, bushes, reducers, clamping helps and lots of other accessories. This is a very valuable machine because of all the accessories!
            core drilling diameter max. 50 mm
            bore depth 2000 mm
            drilling capacity diameter max. 110 mm
            total power requirement 30 kW
            weight of the machine ca. 10 t
            Description :
            Drilling Ø, approx. 2 - 50 mm
            Boring Ø, approx. 100 mm
            Drilling depth, max. (see stroke / mounting length) 1,600 - 2,000 mm
            Stroke of drilling slide, approx. 4,000 mm
            Distance between the two spindle heads 5,000 mm
            Height of centres above guideways 350 / 450 mm

            Drilling feed of drilling slide, infinitely variable 20 - 200 mm/min
            Quick feed of drilling slide 2,500 mm/min
            Spindle speeds via belt disks 260 - 650 / 650 - 1,625 rpm

            Workspindle drive 24 kW
            Drive of coolant pumps 1 x 7.5/15 kW and 1 x 15/28 kW
            Total electrical load, approx. 60 kW - 380 V - 50 Hz
            Total length of machine / guideways 7,500 / 5,000 mm
            Weight, approx. 10,000 kg

            Accessories / Special Features
            * Machine consists of the following elements:
            Main spindle on the left-hand side, followed by the coolant oil supply device. Table group, driven by ball screw
            spindle. Coolant oil supply device with elevated height of centres. At the end is a headstock, Type B 16, with
            drive motor approx. 7.5 kW, n = 900/2400 and 2400/6000. Large coolant device with filter unit. Large selection
            of accessories and drilling tools with Ø up to 100 mm.
            * Machine is suitable for working with a rotating workpiece together with a fixed drilling tool (ELB and BTA Process), as well as for a fixed workpiece and a rotating drilling tool. It can work with internal oil feed (Elb) or with external oil feed (BTA).
            * Complete oil coolant unit with tank and filter and two SIG high pressure pumps. Number of litres can be set: 17 / 40 / 120 or 220 / 500 litres per minute. Capacity approx. 2,500 l.
            * Feed of main slide is via ball screw spindle and infinitely variable DC motor. Mounted on the main slide is at present a table, approx. 800 x 800 mm, cross-adjustable approx. 500 mm, and suitable for holding cubic and cylindrical workpieces. Electric control via cam rail, approx. 2,500 mm long. End switch for quick feed, feed and return.
            * 2 closed 3-point steady rests.
            * FORKHARDT 3-Jaw Chuck, manually operated, Ø approx. 315 mm.
            * Modernized control panel with speed display, feed setting and display, display for kW, switch for feed, quick feed, right/left, etc.
            * 2 separate switch cabinets, separate coolant oil display device, bushes, reducers, clamping helps and lots of other accessories.

            This is a very valuable machine because of all the accessories!
          Datasheet
          Request / Contact
          •
          •
          • 1
          • 2
          • 3
          • 4
          • 5
          • 6
          •
          •

            Perfil del comerciante: Hans - Jürgen Geiger
          Maschinen-Vertrieb GmbH

          Contactar con el comerciante



            Hans - Jürgen Geiger
          Maschinen-Vertrieb GmbH

           James Watt Str. 12
            72555 Metzingen
            Alemania
            (0049)-7123-18040">(0049)-7123-18040
            (0049)-7123-18384
            geiger@geiger-germany.com
            www.geiger-germany.com

          Perfil del comerciante

           MÁS QUE 40 AÑOS DE PRÁCTICA ...
          Nuestra empresa fue fundada por el actual director general, Hans-Jürgen Geiger, en 1968.
          Nos hemos expandido a lo largo de los años y ahora tenemos un área de almacenamiento de más de 10,000 m² (con una capacidad de grúa de hasta 25 toneladas), lo que nos convierte en una de las empresas comerciales más importantes de Europa. Siempre tenemos más de aproximadamente 500 máquinas de segunda mano en stock. Se encuentran disponibles principalmente marcas de calidad alemana y suiza, y se toma mucho cuidado para mantener nuestra tradición de mano de obra superior.
          Nuestro personal está capacitado para hacer todo lo posible para ayudar a nuestros clientes a encontrar una máquina que sea exactamente la adecuada para sus necesidades.
          Estamos orgullosos de nuestro servicio amable y competente. Después de más de 40 años de práctica en este negocio, donde la competencia es difícil, nuestro éxito en Alemania y en el mercado mundial avala nuestra seriedad y la calidad de nuestras máquinas.

             PERTENEMOS A LAS SIGUIENTES ORGANIZACIONES:
            EAMTM Bruselas (Internacional). Somos miembros desde 1980.

             ESPECIALIDAD PRINCIPAL
            Nuestra principal especialidad son las máquinas generadoras de engranajes. Somos uno de los líderes mundiales en esta área y siempre tenemos una gran selección de todo tipo de máquinas de engranajes disponibles.

             MOLINOS DE SUPERFICIE DOBLES LADOS DISKUS
            También nos ocupamos de las amoladoras de superficie de doble cara DISKUS, que casi nunca están disponibles en el mercado. Siempre tenemos la opción de elegir entre 10 y 20 excelentes máquinas en stock.

          SERVICIOS

          Compramos máquinas y plantas de producción de todo el mundo. Si nos vende sus máquinas, puede estar seguro de una pronta inspección, pago, transporte, etc.


             SERVICIO POSTVENTA

            Nuestra administración se esfuerza por brindar a cada cliente una consulta experta antes de la venta; y un servicio postventa confiable, también con respecto a la adquisición de piezas de repuesto, etc. Los clientes pueden visitar nuestros almacenes en cualquier momento. Las máquinas que son de interés pueden ser inspeccionadas bajo el poder, después de la cita previa.


             TRANSPORTE

            Podemos organizar el transporte a un precio razonable si es necesario. Todas las máquinas están protegidas contra la oxidación y se embalan adecuadamente antes de abandonar nuestro stock. Las máquinas que se envían a destinos en el extranjero generalmente se envían en contenedores, y en esta importante área tenemos mucha experiencia en el empaque, por lo que es seguro que las máquinas lleguen en buen estado.


             ACCESORIOS Y PIEZAS DE RECAMBIO

            Nuestro servicio postventa incluye ayudarlo a adquirir accesorios y piezas de repuesto para nuestras máquinas en el futuro.


             Reacondicionamiento y modernización

            También podemos recomendar empresas que se especialicen en reacondicionamiento y reacondicionamiento, etc.


             ESTIMACIONES DE PRECIO

            Si está vendiendo su empresa o sus máquinas de producción, y necesita un presupuesto, nuestro Director, Hans-Jürgen Geiger, es una autoridad calificada (FDM y EAMTM) y estará encantado de ayudarle.


          USTED ESTÁ MUY BIENVENIDO A VISITARNOS

          Cómo encontrar nuestra empresa si está conduciendo:
          En el A81 / A8 (en dirección a Múnich), tome la salida a B27 en dirección a Tuebingen / Reutlingen. Después de aproximadamente 10 km, tome la rama de la dirección Metzingen y después de otro 10, tome la 1. Salga de Metzingen (área industrial Laengenfeld), gire a la izquierda en la primera oportunidad y gire a la izquierda en el cruce, después de 150 m nos encuentra en El lado derecho en el James-Watt-street 12.


             DESCARGAR PDF

          Esquema de indicaciones en formato PDF.

          Con el software gratuito Adobe Acrobat Reader, puede ver e imprimir archivos PDF.


          Nuestra empresa está ubicada cerca del Aeropuerto Internacional de Stuttgart. Estaremos encantados de recogerlo desde allí.

          Hay una estación de tren en Metzingen. Un horario de trenes está disponible en internet en En www.bahn.. Podemos recogerlo en la estación.

          Nuestra oficina y salas de exposición están abiertas de lunes a viernes, de 0800 a 1800. Otras veces solo con cita previa. Estamos cerrados por dos semanas por las vacaciones de Navidad, desde 21st diciembre hasta 7th January.

          Metzingen se encuentra en una zona muy bonita en el sur de Alemania. Es famoso por sus buenos vinos y por sus diversos establecimientos de fábrica (incluidos Hugo Boss y Escada).

          Podemos ayudarlo a encontrar un buen hotel si desea pasar algún tiempo aquí.




          Hans - Jürgen Geiger Maschinen-Vertrieb GmbH  72555 Metzingen James-Watt-Str. 12 Deutschland
          Hans - Jürgen Geiger Maschinen-Vertrieb GmbH

          James-Watt-Str. 12



          Contact Trader


            Hans - Jürgen Geiger Maschinen-Vertrieb GmbH
           James-Watt-Str. 12
            72555 Metzingen
            Deutschland
            (0049)-7123-18040
            (0049)-7123-18384
            geiger@geiger-germany.com
            www.geiger-germany.com
            Contact person:






          Machine category


          Abfallschere · Abkantpresse - hydraulisch · Abwälzfräs- und Stoßmaschine -kombiniert · Bandanlage · Bandsäge - horizontal · Bandsäge - Vertikal · Bandsägeautomat - Horizontal · Bearbeitungszentrum - Horizontal · Bearbeitungszentrum - Universal · Bearbeitungszentrum - Vertikal · Blechentgratungsmaschine · Bohr- und Fräsmaschine · Bohrerschleifmaschine · Bohrmaschine · Bohrwerkstisch · Bügelsägeautomat · CNC Drehmaschine · CNC Drehmaschine - Schrägbettmaschine · CNC-Karusselldrehmaschine - Einständer · Doppelscheibenschleifmaschine · Doppelscheibenschleifmaschine - vertik. · Dreh-,Schwenk-, und Kipptisch · Drehmaschine - zyklengesteuert · Drehmaschine-konventionell-elektronisch · Einstechschleifmaschine · Einständer - Ziehpresse - Hydraulisch · Einständerexzenterpresse · Einständerpresse - Hydraulisch · Entgratmaschine · Exzenterpressen - Einständer · Federprüfmaschine · Feinschleifmaschine · Flachschleifmaschine · Flachschleifmaschine - Horizontal · Flachschleifmaschine - Vertikal · Formfräser-Schärfmaschine · Fräsmaschine - Universal · Fräsmaschine - Vertikal · Fräswerkzeuge · Futterautomat - Einspindel · Gabelstapler - Gas · Gewinde-Schnecken-Schleifmaschine · Gewindebohrmaschine - Vertikal · Gewindefräsmaschine · Gewinderollmaschine · Gewindeschleifmaschine · Gewindewirbelmaschine · Graviermaschine · Hobel-, Fräs- und Schleifmaschine · Hobelmesserschärfmaschine · Hochfrequenzspindel · Honmaschine - handbetätigt · Honmaschine - Innen - Vertikal · Hydraulische - Doppelständerziehpresse · Hydraulische - Viersäulenpresse · Hydraulische - Zweisäulenpresse · Hydraulische Presse · Härteanlage - Induktion · Härteofen · Innen- und Planschleifmaschine · Innenschleifmaschine · Kaltkreissäge · Kaltkreissäge - Automatik · Kaltkreissäge - Vertikal · Kaltwalzmaschine · Kegelrad - Läppmaschine · Kegelrad-Prüfmaschine · Kegelradhärtepresse · Kegelradschleifmaschine · Keilwellenschleifmaschine · Koordinatenbohrmaschine · Koordinatenmeßmaschine · Koordinatenschleifmaschine · Kurbelwellenbandfinishmaschine · Langdrehautomat · Lehrenbohrwerk - Vertikal · Leit- und Zugspindeldrehmaschine · Leiterplattenfertigungsmaschine · Läppmaschine · Messmaschine · Messsystem · Nockenwellenmeßmaschine · Nutenziehmaschine · Oberfräsmaschine · Ofen - Elektro · Plandrehbank · Plattenbohrwerk - Horizontal · Plattensägen vertikal · Pneumatische Presse · Profilprojektor · Präzisionsbandsäge · Punktschweißmaschine · Radialbohrmaschine · Radiale - Schnellbohrmaschine · Richtmaschine · Richtpresse - Doppelständer · Rißprüfmaschine · Rohrbiegemaschine · Rundheits-Meßgerät · Rundschleifmaschine - Außen · Rundschleifmaschine - Universal · Rundtischflachschleifmaschine - Vertikal · Rundtischflächenschleifmaschine - Horiz. · Räummaschine - Innen - Vertikal · Schabrad-Schärfmaschine · Schleifscheibenprofiliergerät · Schneidradschärfmaschine · Schweißanlage · Schwenkbarer - Rundtisch · Senkerodiermaschine · Sonderfeinbohrmaschine · Sondermaschine · Spitzenlose - Rundschleifmaschine · Stanzautomat - Doppelständer · Strangpressen · Säulenbohrmaschine · Tafelschere - hydraulisch · Tafelschere - mechanisch · Teilapparat · Tieflochbohrmaschine · Tischbohrwerk · Trennschleifmaschine · Universal - Rundtisch · Vorschubapparat · Werkzeugfräsmaschine - Universal · Werkzeugschleifmaschine · Werkzeugschleifmaschine - Universal · Wickelmaschine · Wärmeofen · Zahnflankenschleifmaschine · Zahnkantenfräsmaschine · Zahnrad-Abwälzfräsmaschine - horizontal · Zahnrad-Abwälzfräsmaschine - vertikal · Zahnradhonmaschine · Zahnradprüfmaschine · Zahnradschleifmaschine · Zahnradstossmaschine · Zahnstangenfräsmaschine · Zentrumschleifmaschine · Zugprüfmaschine ·
